The transmission can be quickly received by the AIS device installed on mother ship and surrounding ships or approaching helicopter.
| TECHNICAL SPECIFICATION | |
| Frequency: | AIS 1, AIS 2 |
| Frequency error: | ?0.5kHz |
| Power: | 1W |
| AlS Message Type: | MSG 1?MMSI, GNSS position, COG, SOG, UTC? |
| Range: | 4nm typical |
| Operating Time: | ?48 hours |
| Activation method: | Manual or water sensor automatic activation |
| Positioning accuracy: | ?5m?built-in GNSS positioning? |
| BATTERY REQUIREMENTS | |
| Battery Voltage: | DC 6V |
| Capacity: | 1500mAh |
| Storage Temperature: | -30? ~ +70? |
| Storage?Battery Life?: | max 6~8 years (see expiry date on body of product) |
| ENVIRONMENT CONDITIONS | |
| Operating Temperature: | -20? ~ +55? |
| IP Grade: | IP67 |
| OTHERS | |
| Size: | 127(H) x 49.2(W x33.7(D) mm |
| Weight: | abt 180g |
