NSR's new generation of NAVTEX Receiver:
| NAVTEX Receiver | |
| Receiving Frequency: | 518kHz, 490kHz & 4209.5kHz, to receive on three channels simultaneously |
| Mode of Reception: | F1B |
| Sensitivity: | Better than -107dBm |
| Display | |
| Display System: | 7 inch, color LCD, touch screen operation, 154(W) x 87(H) mm |
| Resolution: | 800 x 480 |
| Character number: | English 40 Characters /line |
| Power Supply | DC 24V (10V?38V, 10Watts average) |
| Environment Conditions | |
| Temperature Range: | -20? ~ +55? operational |
| IP Grade: | IP22 (Receiver), IP66 (Antenna & Amplifier) |
| Compass safe distance: | 1.15m (standard) |
| Interface | |
| Input sentences of NMEA IN port: | ZDA, RMC |
| Input sentences of BAM/INS port: | NRM, CRQ, ACK, ACN |
| Output sentences of BAM/INS port: | ALR, NRX, NRM, ACN, ACK, ALF, ALC, ARC, HBT |
| Dimension & Weight | |
| Weight: | 2.3 kg (Receiver) |
| Dimension: | 264(W) x 145(H) x 83(D) mm (Receiver) |
