| Technical Specifications | |
| TX Frequency: | 9.2~9.5GHz |
| Polarization: | Horizontal |
| Radiated Power: | 400mW E.I.R.P |
| Receiver Sensitivity: | Better than -50dBm |
| Battery Requirements (NBT100S) | |
| Battery Voltage: | DC 9V |
| Storage Temp.: | -30? ~ +70? |
| Storage Time: | max 5 years on board (see Note 1) |
| Working Hours: | At least 96 hours |
| Working Environments | |
| Operation Temp.: | -20? ~ +55? |
| Floating Type: | Floatable |
| IP Grade: | IP67 |
| Dimension & Weight | |
| Dimension: | 95(D) × 377(L) mm |
| Weight: | 750g |
